Fiber Access Terminal with Built-in SC Adapters FATM-0316B
  • Fiber Access Terminal with Built-in SC Adapters FATM-0316B
  • Fiber Access Terminal with Built-in SC Adapters FATM-0316B
  • Fiber Access Terminal with Built-in SC Adapters FATM-0316B

Fiber Access Terminal with Built-in SC Adapters FATM-0316B

FATM-0316B fiber access termination box is able to hold up to 16 subscribers. It is used as a termination point for the feeder cable to connect with drop cable in FTTx network system. It integrates fiber splicing, splitting, distribution,storage and cable connection in one solid protection box.

Contact Us
PREV:Optical Terminal Boxes FATM-0416R
NEXT:Fiber Access Terminal Fiber Optic Box Cajas Terminales Opticas FATD-0416B
  • Product Information
  • Feedback
Among those famous fiber access terminal FATM-0316B manufacturers and suppliers in China, Green Telecom Tech Co.,Ltd can offer you customized fiber access terminal FATM-0316B made in China. Our factory is waiting for your contact.


Features
●Protection level: IP65, base and cover sealed with buckled lock  and O-ring system, cable entry ports sealed with rubber.

●Support 48 fiber splices, minimum fiber bending radius: 35mm.

●16 x build-in adapters for drop cable with fast connectors.

●Designated position for the placement of 4pcs of 1:8 splitters.

●Support wall/pole mounted and aerial hanging installation.

●Plug-and-play installation, easy for maintenance and expansion.

●1 mid-span cable entrance(10-16.5mm) for uncut cable and 1 reserved cable entrances for distribution cable gland(8-12mm).

Configuration
Fiber Access Terminal FATM-0316B Parameter

Material

Size

Max Capacity

Nos of built-in adapter

Weight

Color

PC+GF

AxBxC(mm)

Splice 48 fibers

PLC splitter

16pcs SC/UPC

1.4 kgs

Black

290*210*105


4 trays,12fiber/tray

4 pcs of 1x8

or 16pcs SC/APC

Application
● wall-mounted installation
● pole-mounted installation

Standard Accessories

Splice trays x 4pcs, wall mounted kits, fiber protective sleeves, cable protection tube, key, PG 13.5 cable glands fordistribution ports.

Optional Accessories

pole-mounted kits
